ESP65 – 47.1″ Digital Stretch Screen

Retail stretch display monitor

ESP65 – 47.1″ Digital Stretch Screen

Maximum Shelf Visibility with Billboard-Like Clarity

The eShelf® ESP65 is a premium 47.1-inch retail store shelf screen designed to maximize shelf-edge and commercial display visibility. Featuring a sleek, ultra-wide layout with crisp 4K-like resolution, it’s engineered for 24/7 use in retail stores, hospitality environments, transportation hubs, and public-facing venues that demand constant, high-impact messaging.

With an impressive 3840 × 160 resolution, 500 nits brightness, and 16.7 million display colors, the ESP65 delivers ultra-clear content with vivid contrast and wide-angle visibility (89° in all directions). It’s the ideal display for narrow signage areas where traditional screens won’t fit—but high clarity and modern presentation are still essential.

Powered by Android 9.0, the ESP65 runs fully independently—no external media players or network required. Just load your content via TF card or USB, and the display instantly begins playback. This standalone operation makes the screen especially useful for fast, flexible deployment without IT complexity.

Thanks to its T972 quad-core processor, 2GB of RAM (with upgrade options), and 16GB of storage (expandable to 128GB), the ESP65 is well-equipped to run video loops, animated graphics, and slideshows reliably. Designed for continuous 24/7 operation, it’s energy efficient, rugged, and backed by a 1-year warranty.

Whether you’re highlighting promotions, pricing, menus, or brand content, the ESP65 turns any shelf or wall into an eye-catching, real-time communication tool.

Long LCD screen

View Spec Sheet for ESP65 – 47.1” Digital Stretch Screen >

Long LCD screen

View Spec Sheet for Wide Input Model ESP65 – 47.1” Digital Stretch Screen >

Why Choose the ESP65?

✔️ Small but powerful visual presence
✔️ Plug-and-play simplicity with Android OS
✔️ Ideal for high-density product areas
✔️ Efficient power usage and easy installation

In-aisle digital signage

Screen Size

47.1″

In-aisle digital signage

Resolution

3840 (V) × 160 (H)

In-aisle digital signage

Brightness

500 cd/m²

In-aisle digital signage

Contrast Ratio

1000:1

In-aisle digital signage

Frequency

60 Hz

In-aisle digital signage

Dimensions

1214.8 × 68.8 × 25.0 mm

In-aisle digital signage

Backlight

LED

In-aisle digital signage

Color Depth

16.7M

In-aisle digital signage

Active Area

1196.16(H) × 49.84(V) mm

In-aisle digital signage

Viewing Angle

89°/89°/89°/89°

In-aisle digital signage

Lifespan

50,000 hours

Electronic retail label

Perfect For:

  • Retail shelf-edge price and product displays
  • Smart labeling in convenience and electronics stores
  • Promotional visuals in compact spaces
  • Multi-screen messaging setups

Key Benefits

  • Ultra-Wide 47.1” Format – Delivers a panoramic digital signage experience with crystal-clear clarity
  • Vivid and Bright – 500 nits brightness, 1000:1 contrast, and 16.7M colors ensure your content stands out
  • Standalone Playback – Operates independently with Android 9.0—no internet or external players needed
  • Flexible Content Input – Upload media via USB or TF card (up to 128GB supported)
  • Durable and Reliable – Built for 24/7 operation with a 50,000-hour lifespan
  • Global Compatibility – Powered by 12V DC and supports wide temperature and humidity environments
  • Energy Efficient – Runs on just ≤35W of power

System & Performance

  • Operating System: Android 9.0
  • CPU: T972 Quad-core ARM Cortex-A55 @ 1.9GHz
  • RAM: 2GB (upgradeable to 4GB/8GB)
  • Storage: 16GB eMMC (optional 32GB/64GB)
  • Expandable Storage: TF card slot supports up to 128GB

Media Format Support

  • Video: 1080p @ 60fps (H.265, H.264, VC-1, MPEG-1/2/4, VP8)
  • Audio: MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A, 3GPP
  • Images: JPG, BMP, PNG (supports slideshow, rotation, zoom)

Connectivity & Interfaces

  • Wi-Fi: Built-in (2.4G standard, optional dual-band 2.4G/5G)
  • Bluetooth: v4.2
  • Ports:
    • 1× Micro USB (OTG)
    • 1× TF Card Slot
    • 1× USB-A
    • 1× USB-C Power Input (DC 12V with special adapter required)

Power & Environmental

  • Power Consumption: ≤35W
  • Voltage Input: DC 12V
  • Operating Temperature: 0℃ to 50℃
  • Storage Temperature: -20℃ to 60℃
  • Humidity (Op/Storage): 10%–85% / 5%–95%
  • Atmospheric Pressure: 86kPa – 104kPa
  • Net Weight: ≤3 kg
  • Packing (5 units): 1300 × 380 × 150 mm
  • Gross Weight (5 units): 17.6 kg

Accessories & Warranty

  • Optional Accessories: Mounting bracket, power adapter, OTG cable
  • Warranty: 1 year standard (extension options available)

Ready to Deploy the ESP65?

Reach out today for pricing, demos, and deployment options.
