ESP50 – 35″ Digital Stretch Screen

Electronic shelf label screen

ESP50 – 35″ Digital Stretch Screen

Sleek, Ultra-Wide 4K Signage Built for Continuous Performance

The eshelf ESP50A is a professional-grade 35-inch retail store shelf display engineered to deliver vibrant, panoramic content in compact spaces. Designed for 24/7 operation, this ultra-wide display excels in commercial environments such as retail, transportation, hospitality, and shelf-edge advertising where space efficiency and visual impact matter most.

With an impressive 3840 × 200 resolution, this screen offers ultra-sharp, high-definition output in a 35-inch wide format, perfect for showing detailed menus, promotional content, or branded visuals. Powered by Android 9.0, the ESP50A supports stand-alone playback with no network connection needed—just plug, load your content, and play.

The device runs on a powerful T972 quad-core processor and comes equipped with 2GB RAM and 16GB storage (upgradeable to 8GB RAM and 64GB storage). Supporting up to 128GB TF card expansion, the ESP50A is flexible and future-proof. It also features modern connectivity including USB, Micro USB (OTG), TF card slot, and USB-C power input, as well as dual-band Wi-Fi (optional 5G) and Bluetooth 4.2.

Despite its expansive screen size, the unit is lightweight and power-efficient, consuming only ≤18W, while delivering rich color depth (1.07 billion colors), a 178° viewing angle, and 400 nits brightness—making it perfect for both indoor and semi-bright spaces.

Long LCD screen

View Spec Sheet for ESP50 – 35” Digital Stretch Screen >

Long LCD screen

View Spec Sheet for Wide Input Model ESP50 – 35” Digital Stretch Screen >

Why Choose the ESP30?

✔️ Small but powerful visual presence
✔️ Plug-and-play simplicity with Android OS
✔️ Ideal for high-density product areas
✔️ Efficient power usage and easy installation

In-aisle digital signage

Screen Size

35″

In-aisle digital signage

Resolution

3840 (V) × 200 (H)

In-aisle digital signage

Brightness

400 cd/m²

In-aisle digital signage

Contrast Ratio

1000:1

In-aisle digital signage

Frequency

60 Hz

In-aisle digital signage

Dimensions

891.6 × 60.4 × 23.0 mm

In-aisle digital signage

Backlight

LED

In-aisle digital signage

Color Depth

1.07 Billion (10-bit)

In-aisle digital signage

Response Time

8 ms

In-aisle digital signage

Active Area

878.4 × 48.19 mm

In-aisle digital signage

Viewing Angle

178° (Vertical & Horizontal)

In-aisle digital signage

Lifespan

30,000 hours

Electronic retail label

Perfect For:

  • Retail shelf-edge price and product displays
  • Smart labeling in convenience and electronics stores
  • Promotional visuals in compact spaces
  • Multi-screen messaging setups

Key Benefits

  • Ultra-Wide 35” 4K Display – 3840 × 200 resolution in a panoramic stretch format for dynamic shelf-edge signage
  • 24/7 Commercial Operation – Designed for continuous use with 30,000-hour LED lifespan
  • Stand-Alone Simplicity – Android-powered with onboard memory; no network required
  • Flexible Media Support – Handles a wide range of video, image, and audio formats
  • Smart Connectivity – Built-in Wi-Fi, Bluetooth 4.2, USB ports, and TF card input
  • Energy Efficient – Operates on ≤18W with reliable DC 12V power input
  • Expandable & Upgradeable – RAM and storage options with support for up to 128GB via TF card

System & Performance

  • OS: Android 9.0
  • CPU: T972 Quad-core ARM Cortex-A55, 1.9GHz
  • RAM: 2GB (optional 4GB/8GB)
  • Storage: 16GB eMMC (optional 32GB/64GB)
  • Expandable Storage: TF card up to 128GB

Media Format Support

  • Video: H.265, H.264, VC-1, MPEG-1/2/4, VP8 — up to 1080p @ 60fps
  • Audio: MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A, 3GPP
  • Images: JPG, BMP, PNG (slideshow, rotation, zoom supported)

Connectivity & Interfaces

  • Wi-Fi: Built-in 2.4G (optional dual-band 2.4G/5G)
  • Bluetooth: v4.2
  • Ports:
    • 1× Micro USB (OTG)
    • 1× USB-A
    • 1× TF Card Slot
    • 1× USB-C Power Input (DC 12V)

Power & Environmental

  • Power Consumption: ≤18W
  • Voltage Input: DC 12V
  • Operating Temp: 0℃ to 50℃
  • Storage Temp: -20℃ to 60℃
  • Humidity (Operating/Storage): 10%–85% / 5%–95%
  • Net Weight: ≤1.5 kg
  • Packing Dimensions (5 units): 1120 × 320 × 140 mm
  • Gross Weight (5 units): 7.55 kg

Accessories & Warranty

  • Optional Accessories: Power adapter, mounting bracket, OTG cable
  • Warranty: 1 year standard (extended options available)

Ready to Deploy the ESP50?

Reach out today for pricing, demos, and deployment options.
